The complete tour
A twelve-page document that is its own reference: every element and option, each shown with its JSON.
Text and flow, graphics and codes, tables, charts and layout options, with a clickable table of contents whose page numbers come from the renderer.
Every element
Clickable TOC
#PAGE_OF tokens
12 pages
render_features.rb
ruby
require 'json'
require 'soli/pdf'
template = JSON.parse(File.read('features.template.json'))
data = JSON.parse(File.read('features.data.json'))
pdf = Soli::PDF.render(
template: template,
data: data,
title: 'The soli-pdf template reference'
)
File.binwrite('features.pdf', pdf)Run it yourself
- Add the gem to your Gemfile — see Installation.
- Download features.template.json and features.data.json.
- Run
ruby render_features.rb.
features.template.json
json
{
"fonts": [
"TitilliumWeb"
],
"options": {
"page": "a4",
"margins": {
"top": 42,
"right": 50,
"bottom": 46,
"left": 50
},
"header_height": 34,
"backgroundImage": {
"pages": "first"
}
},
"header": [
{
"type": "image",
"width": 15,
},
{
"type": "move",
"x": 0,
"y": 1
},
{
"type": "paragraph",
"value": "the soli-pdf template reference",
"options": {
"alignment": "right",
"fontSize": 8.5,
"color": "94a3b8"
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "hr",
"color": "e2e8f0",
"thickness": 0.6
}
],
"footer": [
{
"type": "paragraph",
"value": "soli-pdf · page #PAGE# of #TOTAL_PAGE#",
"options": {
"alignment": "center",
"fontSize": 8,
"color": "94a3b8"
}
}
],
"content": [
{
"type": "rect",
"width": 495,
"height": 6,
"fill": "f59e0b",
"radius": 3
},
{
"type": "move",
"x": 0,
"y": 6
},
{
"type": "rect",
"width": 495,
"height": 150,
"fill": "0F766E",
"radius": 14
},
{
"type": "move",
"x": 30,
"y": 30
},
{
"type": "image",
"width": 52,
},
{
"type": "move",
"x": 72,
"y": 6
},
{
"type": "paragraph",
"value": "The soli-pdf template",
"options": {
"fontSize": 25,
"fontWeight": "bold",
"color": "ffffff",
"bookmark": "Cover",
"anchor": "sec-cover"
}
},
{
"type": "paragraph",
"value": "A complete, worked reference — rendered by the engine it documents.",
"options": {
"fontSize": 10.5,
"color": "ccfbf1",
"italic": true
}
},
{
"type": "move",
"x": 0,
"y": 20
},
{
"type": "paragraph",
"spans": [
{
"text": "• ",
"color": "f59e0b"
},
{
"text": "every element & option",
"color": "ffffff",
"fontSize": 9.5
},
{
"text": " • ",
"color": "f59e0b"
},
{
"text": "each shown with its JSON",
"color": "ffffff",
"fontSize": 9.5
},
{
"text": " • ",
"color": "f59e0b"
},
{
"text": "one template, one call",
"color": "ffffff",
"fontSize": 9.5
}
],
"options": {
"fontSize": 9.5
}
},
{
"type": "move",
"x": -102,
"y": 56
},
{
"type": "paragraph",
"value": "This document is itself a soli-pdf template. Everything you see — the cover band, the tables, the charts, the QR code — was produced by a single JSON template passed to one pdf_render() call, with no browser and no HTML. Each feature below is shown twice: the JSON that declares it, and the result it renders to.",
"options": {
"fontSize": 10.5,
"color": "334155",
"lineHeight": 1.5,
"alignment": "justify"
}
},
{
"type": "move",
"x": 0,
"y": 26
},
{
"type": "paragraph",
"value": "CONTENTS",
"options": {
"fontSize": 10,
"fontWeight": "bold",
"mono": true,
"color": "0F766E"
}
},
{
"type": "move",
"x": 0,
"y": 6
},
{
"type": "hr",
"color": "e2e8f0",
"thickness": 0.8
},
{
"type": "move",
"x": 0,
"y": 12
},
{
"type": "paragraph",
"spans": [
{
"text": "1 ",
"fontWeight": "bold",
"color": "0F766E",
"mono": true
},
{
"text": "Text & flow",
"fontWeight": "bold",
"color": "0f172a"
},
{
"text": " — paragraphs, spans, lists",
"color": "64748b",
"fontSize": 9
}
],
"options": {
"fontSize": 11.5,
"linkTo": "sec-text"
}
},
{
"type": "move",
"x": 0,
"y": -13.8
},
{
"type": "paragraph",
"value": "p. #PAGE_OF:sec-text#",
"options": {
"fontSize": 9.5,
"color": "2563eb",
"alignment": "right",
"linkTo": "sec-text"
}
},
{
"type": "move",
"x": 0,
"y": 13
},
{
"type": "paragraph",
"spans": [
{
"text": "2 ",
"fontWeight": "bold",
"color": "0F766E",
"mono": true
},
{
"text": "Graphics & codes",
"fontWeight": "bold",
"color": "0f172a"
},
{
"text": " — rects, strokes, images, QR, barcodes",
"color": "64748b",
"fontSize": 9
}
],
"options": {
"fontSize": 11.5,
"linkTo": "sec-graphics"
}
},
{
"type": "move",
"x": 0,
"y": -13.8
},
{
"type": "paragraph",
"value": "p. #PAGE_OF:sec-graphics#",
"options": {
"fontSize": 9.5,
"color": "2563eb",
"alignment": "right",
"linkTo": "sec-graphics"
}
},
{
"type": "move",
"x": 0,
"y": 13
},
{
"type": "paragraph",
"spans": [
{
"text": "3 ",
"fontWeight": "bold",
"color": "0F766E",
"mono": true
},
{
"text": "Tables",
"fontWeight": "bold",
"color": "0f172a"
},
{
"text": " — data binding, merges, rich cells",
"color": "64748b",
"fontSize": 9
}
],
"options": {
"fontSize": 11.5,
"linkTo": "sec-tables"
}
},
{
"type": "move",
"x": 0,
"y": -13.8
},
{
"type": "paragraph",
"value": "p. #PAGE_OF:sec-tables#",
"options": {
"fontSize": 9.5,
"color": "2563eb",
"alignment": "right",
"linkTo": "sec-tables"
}
},
{
"type": "move",
"x": 0,
"y": 13
},
{
"type": "paragraph",
"spans": [
{
"text": "4 ",
"fontWeight": "bold",
"color": "0F766E",
"mono": true
},
{
"text": "Charts",
"fontWeight": "bold",
"color": "0f172a"
},
{
"text": " — bar, line, pie, donut",
"color": "64748b",
"fontSize": 9
}
],
"options": {
"fontSize": 11.5,
"linkTo": "sec-charts"
}
},
{
"type": "move",
"x": 0,
"y": -13.8
},
{
"type": "paragraph",
"value": "p. #PAGE_OF:sec-charts#",
"options": {
"fontSize": 9.5,
"color": "2563eb",
"alignment": "right",
"linkTo": "sec-charts"
}
},
{
"type": "move",
"x": 0,
"y": 13
},
{
"type": "paragraph",
"spans": [
{
"text": "5 ",
"fontWeight": "bold",
"color": "0F766E",
"mono": true
},
{
"text": "Layout & render options",
"fontWeight": "bold",
"color": "0f172a"
},
{
"text": " — columns, branches, the render call",
"color": "64748b",
"fontSize": 9
}
],
"options": {
"fontSize": 11.5,
"linkTo": "sec-layout"
}
},
{
"type": "move",
"x": 0,
"y": -13.8
},
{
"type": "paragraph",
"value": "p. #PAGE_OF:sec-layout#",
"options": {
"fontSize": 9.5,
"color": "2563eb",
"alignment": "right",
"linkTo": "sec-layout"
}
},
{
"type": "move",
"x": 0,
"y": 13
},
{
"type": "hr",
"color": "e2e8f0",
"thickness": 0.8
},
{
"type": "move",
"x": 0,
"y": 10
},
{
"type": "paragraph",
"value": "solilang.com/docs/builtins/pdf · edit this template live in the playground",
"options": {
"fontSize": 8.5,
"color": "94a3b8",
"italic": true,
"link": "https://solilang.com/docs/builtins/pdf"
}
},
{
"type": "page_break"
},
{
"type": "rect",
"width": 30,
"height": 30,
"fill": "0F766E",
"radius": 8
},
{
"type": "move",
"x": 11,
"y": 6
},
{
"type": "paragraph",
"value": "1",
"options": {
"fontSize": 13,
"fontWeight": "bold",
"color": "ffffff"
}
},
{
"type": "move",
"x": 30,
"y": -19
},
{
"type": "paragraph",
"value": "Text & flow",
"options": {
"fontSize": 20,
"fontWeight": "bold",
"color": "0f172a",
"bookmark": "Text & flow",
"anchor": "sec-text"
}
},
{
"type": "move",
"x": -41,
"y": 12
},
{
"type": "paragraph",
"value": "Paragraphs, inline rich text, and lists — the words on the page.",
"options": {
"fontSize": 10,
"color": "64748b",
"italic": true
}
},
{
"type": "move",
"x": 0,
"y": 10
},
{
"type": "hr",
"color": "e2e8f0",
"thickness": 0.8
},
{
"type": "move",
"x": 0,
"y": 16
},
{
"type": "paragraph",
"value": "paragraph",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 167.35000000000002,
"bookmark": "paragraph",
"bookmarkLevel": 2,
"anchor": "sec-para"
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "The workhorse: a wrapped block of text. Options set size, weight, colour and alignment.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 58.525,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 58.525,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"paragraph\",\n \"value\": \"Invoice $${invoice.number}\",\n \"options\": { \"fontSize\": 16, \"fontWeight\": \"bold\", \"color\": \"0F766E\" } }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "paragraph",
"value": "Invoice INV-2026-0042",
"options": {
"fontSize": 16,
"fontWeight": "bold",
"color": "0F766E"
}
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "alignment & justify",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 167.0,
"bookmark": "alignment & justify",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "alignment is left · center · right · justify. justify spreads each full line to both margins by widening word gaps; the last line stays left.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 45.35,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 45.35,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"paragraph\", \"options\": { \"alignment\": \"justify\" },\n \"value\": \"soli-pdf typesets text itself...\" }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "paragraph",
"value": "soli-pdf typesets text itself — measuring, wrapping and justifying every line in-process, with no headless browser in sight. This paragraph is set justify, so both edges line up while the final line stays left.",
"options": {
"fontSize": 10,
"color": "334155",
"alignment": "justify",
"lineHeight": 1.4
}
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "lineHeight & spacing",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 180.175,
"bookmark": "lineHeight & spacing",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "lineHeight multiplies the leading (engine default 1.2); spacing adds points below the block, replacing a trailing move.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 58.525,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 58.525,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"paragraph\",\n \"options\": { \"lineHeight\": 1.7 },\n \"value\": \"Loose leading lets dense reference text breathe.\" }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "paragraph",
"value": "Loose leading lets dense reference text breathe — this block is set at lineHeight 1.7, so the wrapped lines sit further apart than the 1.2 default.",
"options": {
"fontSize": 10,
"color": "334155",
"lineHeight": 1.7
}
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "spans — inline rich text",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 232.875,
"bookmark": "spans — inline rich text",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "spans mix weight, size, colour, links, underline and strike within one wrapped flow; each span inherits the paragraph options it omits.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 111.22500000000001,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 111.22500000000001,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"paragraph\", \"spans\": [\n { \"text\": \"Mix \" }, { \"text\": \"bold\", \"fontWeight\": \"bold\" },\n { \"text\": \", a \", }, { \"text\": \"link\", \"link\": \"https://solilang.com\",\n \"color\": \"2563eb\", \"underline\": true },\n { \"text\": \", and a redline was \" },\n { \"text\": \"99.00\", \"strike\": true, \"color\": \"b91c1c\" },\n { \"text\": \" now 79.00\", \"fontWeight\": \"bold\", \"color\": \"0F766E\" } ] }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "paragraph",
"spans": [
{
"text": "Mix "
},
{
"text": "bold",
"fontWeight": "bold"
},
{
"text": ", "
},
{
"text": "italic",
"italic": true
},
{
"text": ", "
},
{
"text": "mono",
"mono": true
},
{
"text": ", a "
},
{
"text": "link",
"link": "https://solilang.com",
"color": "2563eb",
"underline": true
},
{
"text": ", and a redline was "
},
{
"text": "99.00",
"strike": true,
"color": "b91c1c"
},
{
"text": " now "
},
{
"text": "79.00 EUR",
"fontWeight": "bold",
"color": "0F766E"
}
],
"options": {
"fontSize": 10.5
}
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "list — ordered · nested · custom marker",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 219.7,
"bookmark": "list — ordered · nested · custom marker",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "ordered numbers from start; items may nest a list or carry spans; marker and indent tune the look.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 84.875,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 84.875,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"list\", \"ordered\": true, \"items\": [\n \"Grind the beans\",\n { \"text\": \"Brew\", \"list\": { \"items\": [\"Bloom 30 s\", \"Pour to 250 g\"] } },\n { \"spans\": [ { \"text\": \"Enjoy \" },\n { \"text\": \"responsibly\", \"italic\": true } ] } ] }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "list",
"ordered": true,
"options": {
"fontSize": 10,
"color": "334155"
},
"spacing": 3,
"items": [
"Grind the beans",
{
"text": "Brew",
"list": {
"items": [
"Bloom 30 s",
"Pour to 250 g"
]
}
},
{
"spans": [
{
"text": "Enjoy "
},
{
"text": "responsibly",
"italic": true
}
]
}
]
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "page_break"
},
{
"type": "rect",
"width": 30,
"height": 30,
"fill": "0F766E",
"radius": 8
},
{
"type": "move",
"x": 11,
"y": 6
},
{
"type": "paragraph",
"value": "2",
"options": {
"fontSize": 13,
"fontWeight": "bold",
"color": "ffffff"
}
},
{
"type": "move",
"x": 30,
"y": -19
},
{
"type": "paragraph",
"value": "Graphics & codes",
"options": {
"fontSize": 20,
"fontWeight": "bold",
"color": "0f172a",
"bookmark": "Graphics & codes",
"anchor": "sec-graphics"
}
},
{
"type": "move",
"x": -41,
"y": 12
},
{
"type": "paragraph",
"value": "Boxes, strokes, images, and machine-readable codes.",
"options": {
"fontSize": 10,
"color": "64748b",
"italic": true
}
},
{
"type": "move",
"x": 0,
"y": 10
},
{
"type": "hr",
"color": "e2e8f0",
"thickness": 0.8
},
{
"type": "move",
"x": 0,
"y": 16
},
{
"type": "paragraph",
"value": "move — the cursor primitive",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 97.825,
"bookmark": "move — the cursor primitive",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "The layout primitive. +y is down, −y up, +x right. rect, line, ellipse, image, qr and barcode draw at the cursor without advancing it — move positions them (that is how these result rows are placed).",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 32.175,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 32.175,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"move\", \"x\": 20, \"y\": -8 }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "rect — panels & boxes",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 177.0,
"bookmark": "rect — panels & boxes",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "A filled and/or stroked box. radius rounds the corners; dash strokes the border. Drawn at the cursor, never advancing it.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 45.35,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 45.35,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"rect\", \"width\": 495, \"height\": 44,\n \"fill\": \"f0fdfa\", \"border\": \"99f6e4\", \"radius\": 10 }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "rect",
"width": 240,
"height": 44,
"fill": "f0fdfa",
"border": "99f6e4",
"borderWidth": 0.9,
"radius": 10
},
{
"type": "move",
"x": 14,
"y": 15.0
},
{
"type": "paragraph",
"value": "rounded · filled · bordered",
"options": {
"fontSize": 9.5,
"fontWeight": "bold",
"color": "0F766E"
}
},
{
"type": "move",
"x": -14,
"y": 17.6
},
{
"type": "move",
"x": 255,
"y": -44
},
{
"type": "rect",
"width": 240,
"height": 44,
"border": "94a3b8",
"borderWidth": 1,
"radius": 6,
"dash": [
5,
3
]
},
{
"type": "move",
"x": 14,
"y": 15.0
},
{
"type": "paragraph",
"value": "\"dash\": [5, 3]",
"options": {
"fontSize": 9.5,
"fontWeight": "bold",
"color": "64748b"
}
},
{
"type": "move",
"x": -14,
"y": 17.6
},
{
"type": "move",
"x": -255,
"y": 0
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "ellipse · line · hr — strokes & dots",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 180.175,
"bookmark": "ellipse · line · hr — strokes & dots",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "ellipse is a circle when rx == ry; line runs from the cursor to +(dx, dy); hr rules across the width (or an explicit width). line & hr take a dash too.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 58.525,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 58.525,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"ellipse\", \"rx\": 6, \"ry\": 6, \"fill\": \"0F766E\" }\n{ \"type\": \"line\", \"dx\": 170, \"dy\": 0, \"dash\": [5, 3] }\n{ \"type\": \"hr\", \"color\": \"f59e0b\", \"thickness\": 1.4, \"width\": 220 }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "ellipse",
"rx": 6,
"ry": 6,
"fill": "16a34a"
},
{
"type": "move",
"x": 20,
"y": 0
},
{
"type": "ellipse",
"rx": 6,
"ry": 6,
"fill": "eab308"
},
{
"type": "move",
"x": 20,
"y": 0
},
{
"type": "ellipse",
"rx": 6,
"ry": 6,
"fill": "dc2626"
},
{
"type": "move",
"x": 28,
"y": -1
},
{
"type": "ellipse",
"rx": 24,
"ry": 8,
"fill": "e0f2fe",
"border": "0284c7",
"borderWidth": 0.8
},
{
"type": "move",
"x": 70,
"y": 6
},
{
"type": "line",
"dx": 170,
"dy": 0,
"color": "94a3b8",
"width": 1,
"dash": [
5,
3
]
},
{
"type": "move",
"x": -138,
"y": 16
},
{
"type": "hr",
"color": "f59e0b",
"thickness": 1.4,
"width": 220
},
{
"type": "move",
"x": 0,
"y": 6
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "image — raster & SVG",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 183.0,
"bookmark": "image — raster & SVG",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "PNG · JPEG · WebP · GIF and SVG (auto-rasterised, so vector logos stay crisp). width alone derives the height from the aspect ratio.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 45.35,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 45.35,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "image",
"width": 150,
},
{
"type": "move",
"x": 0,
"y": 55
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "qr — scan-to-pay & text",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 261.35,
"bookmark": "qr — scan-to-pay & text",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "kind \"epc\" builds a SEPA GiroCode from the payment data — scan it in a banking app to pre-fill the transfer; kind \"text\" encodes any string. Both rasterised locally, no network.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 71.7,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 71.7,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"qr\", \"kind\": \"epc\", \"width\": 88,\n \"name\": \"$${payment.name}\", \"iban\": \"$${payment.iban}\",\n \"amount\": \"$${payment.amount}\", \"currency\": \"EUR\",\n \"remittance\": \"$${doc.ref}\" }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "qr",
"kind": "epc",
"name": "${payment.name}",
"iban": "${payment.iban}",
"amount": "${payment.amount}",
"currency": "EUR",
"remittance": "${doc.ref}",
"width": 88
},
{
"type": "move",
"x": 116,
"y": 0
},
{
"type": "qr",
"kind": "text",
"value": "https://solilang.com/docs/builtins/pdf",
"width": 88
},
{
"type": "move",
"x": -116,
"y": 94
},
{
"type": "paragraph",
"value": "left: EPC scan-to-pay (79.00 EUR to Soli Demo SARL) · right: a URL",
"options": {
"fontSize": 8.5,
"color": "94a3b8",
"italic": true,
"spacing": 2
}
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "barcode — code128 · ean13",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 191.0,
"bookmark": "barcode — code128 · ean13",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "1-D barcodes. code128 takes any printable ASCII; ean13 takes 12 digits and computes the check digit. humanReadable prints the caption under the bars.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 45.35,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 45.35,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"barcode\", \"symbology\": \"code128\", \"value\": \"$${doc.ref}\",\n \"width\": 210, \"height\": 46, \"humanReadable\": true }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "barcode",
"symbology": "code128",
"value": "${doc.ref}",
"width": 210,
"height": 46,
"humanReadable": true
},
{
"type": "move",
"x": 250,
"y": 0
},
{
"type": "barcode",
"symbology": "ean13",
"value": "400638133393",
"width": 185,
"height": 46,
"humanReadable": true
},
{
"type": "move",
"x": -250,
"y": 62
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "page_break"
},
{
"type": "rect",
"width": 30,
"height": 30,
"fill": "0F766E",
"radius": 8
},
{
"type": "move",
"x": 11,
"y": 6
},
{
"type": "paragraph",
"value": "3",
"options": {
"fontSize": 13,
"fontWeight": "bold",
"color": "ffffff"
}
},
{
"type": "move",
"x": 30,
"y": -19
},
{
"type": "paragraph",
"value": "Tables",
"options": {
"fontSize": 20,
"fontWeight": "bold",
"color": "0f172a",
"bookmark": "Tables",
"anchor": "sec-tables"
}
},
{
"type": "move",
"x": -41,
"y": 12
},
{
"type": "paragraph",
"value": "Grids of cells — data-bound rows, merges, rich content, and per-table stamps.",
"options": {
"fontSize": 10,
"color": "64748b",
"italic": true
}
},
{
"type": "move",
"x": 0,
"y": 10
},
{
"type": "hr",
"color": "e2e8f0",
"thickness": 0.8
},
{
"type": "move",
"x": 0,
"y": 16
},
{
"type": "paragraph",
"value": "table — data binding · header · stripe",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 292.525,
"bookmark": "table — data binding · header · stripe",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "data binds the template row to an array, repeating it per item. The header_columns band repeats on every page; options.stripe zebra-fills every second body row.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 84.875,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 84.875,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"table\", \"data\": \"items\",\n \"header_columns\": [ { \"text\": \"SERVICE\", \"width\": 250 }, ... ],\n \"rows\": [ [ { \"text\": \"$${name}\", \"width\": 250 }, ... ] ],\n \"options\": { \"header\": { \"fillColor\": \"0F766E\", \"textColor\": \"FFFFFF\" },\n \"stripe\": \"f1f5f9\" } }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "table",
"data": "items",
"header_columns": [
{
"text": "SERVICE",
"width": 250,
"fontWeight": "bold",
"fontSize": 9.5
},
{
"text": "QTY",
"width": 60,
"fontWeight": "bold",
"fontSize": 9.5,
"alignment": "right"
},
{
"text": "AMOUNT",
"width": 185,
"fontWeight": "bold",
"fontSize": 9.5,
"alignment": "right"
}
],
"rows": [
[
{
"text": "${name}",
"width": 250,
"fontSize": 10
},
{
"text": "${qty}",
"width": 60,
"fontSize": 10,
"alignment": "right"
},
{
"text": "${amount}",
"width": 185,
"fontSize": 10,
"alignment": "right"
}
]
],
"options": {
"header": {
"fillColor": "0F766E",
"textColor": "FFFFFF",
"borderColor": "0F766E"
},
"stripe": "f1f5f9",
"padding_x": 8,
"padding_y": 6
}
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "colspan & per-cell fill — a totals row",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 193.35000000000002,
"bookmark": "colspan & per-cell fill — a totals row",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "colspan merges a cell across column slots; a cell's own fill paints its background over the stripe — the recipe for summary and total rows.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 71.7,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 71.7,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"rows\": [ [\n { \"text\": \"TOTAL DUE\", \"colspan\": 2, \"alignment\": \"right\",\n \"fontWeight\": \"bold\" },\n { \"text\": \"$${doc.total}\", \"alignment\": \"right\", \"fill\": \"fef3c7\" } ] ] }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "table",
"header_columns": [
{
"text": "",
"width": 250
},
{
"text": "",
"width": 60
},
{
"text": "",
"width": 185
}
],
"rows": [
[
{
"text": "TOTAL DUE",
"colspan": 2,
"alignment": "right",
"fontWeight": "bold",
"fontSize": 10.5,
"borderSides": {
"top": "true",
"bottom": "true",
"left": "true",
"right": "true"
},
"borderColor": "0F766E"
},
{
"text": "${doc.total}",
"alignment": "right",
"fontWeight": "bold",
"fontSize": 10.5,
"fill": "fef3c7",
"borderSides": {
"top": "true",
"bottom": "true",
"left": "true",
"right": "true"
},
"borderColor": "0F766E"
}
]
],
"options": {
"padding_x": 8,
"padding_y": 6
}
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "rich cells · borderSides · per-table watermark",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 289.35,
"bookmark": "rich cells · borderSides · per-table watermark",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "A rich cell stacks text lines and an image in one cell; borderSides sets each edge with a borderColor; the table carries its own centred watermark.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 71.7,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 71.7,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"table\",\n \"watermark\": { \"text\": \"SAMPLE\", \"fontSize\": 44, \"color\": \"fecaca\" },\n \"rows\": [ [ { \"content\": [ { \"type\": \"text\", ... },\n { \"type\": \"image\", ... } ] }, ... ] ] }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "move",
"x": 0,
"y": 14
},
{
"type": "table",
"watermark": {
"text": "SAMPLE",
"fontSize": 44,
"color": "fecaca"
},
"rows": [
[
{
"width": 300,
"borderSides": {
"top": "true",
"bottom": "true",
"left": "true",
"right": "true"
},
"borderColor": "0F766E",
"content": [
{
"type": "text",
"value": "${payment.name}",
"fontSize": 11,
"fontWeight": "bold"
},
{
"type": "text",
"value": "IBAN ${payment.iban}",
"fontSize": 9
},
{
"type": "image",
"width": 74,
}
]
},
{
"text": "valign \"bottom\"",
"fontSize": 10,
"alignment": "right",
"valign": "bottom"
}
]
],
"options": {
"padding_x": 10,
"padding_y": 9
}
},
{
"type": "move",
"x": 0,
"y": 20
},
{
"type": "move",
"x": 0,
"y": 30
},
{
"type": "paragraph",
"value": "repeat — block-level data binding",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 228.525,
"bookmark": "repeat — block-level data binding",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "The block-level analogue of a data-bound row: lay out any elements once per array item, with $${field} scoped to each item.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 84.875,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 84.875,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"repeat\", \"data\": \"milestones\", \"content\": [\n { \"type\": \"paragraph\", \"spans\": [\n { \"text\": \"$${date} \", \"mono\": true, \"color\": \"64748b\" },\n { \"text\": \"$${title}\", \"fontWeight\": \"bold\" },\n { \"text\": \" — $${note}\" } ] } ] }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "repeat",
"data": "milestones",
"content": [
{
"type": "paragraph",
"spans": [
{
"text": "${date} ",
"mono": true,
"fontSize": 9,
"color": "64748b"
},
{
"text": "${title}",
"fontWeight": "bold",
"color": "0f172a"
},
{
"text": " — ${note}",
"color": "475569"
}
],
"options": {
"fontSize": 10
}
},
{
"type": "move",
"x": 0,
"y": 5
}
]
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "page_break"
},
{
"type": "rect",
"width": 30,
"height": 30,
"fill": "0F766E",
"radius": 8
},
{
"type": "move",
"x": 11,
"y": 6
},
{
"type": "paragraph",
"value": "4",
"options": {
"fontSize": 13,
"fontWeight": "bold",
"color": "ffffff"
}
},
{
"type": "move",
"x": 30,
"y": -19
},
{
"type": "paragraph",
"value": "Charts",
"options": {
"fontSize": 20,
"fontWeight": "bold",
"color": "0f172a",
"bookmark": "Charts",
"anchor": "sec-charts"
}
},
{
"type": "move",
"x": -41,
"y": 12
},
{
"type": "paragraph",
"value": "Bar, line, pie and donut — drawn from the data, no plotting library.",
"options": {
"fontSize": 10,
"color": "64748b",
"italic": true
}
},
{
"type": "move",
"x": 0,
"y": 10
},
{
"type": "hr",
"color": "e2e8f0",
"thickness": 0.8
},
{
"type": "move",
"x": 0,
"y": 16
},
{
"type": "paragraph",
"value": "chart — grouped bars · multi-series · gridlines",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 327.35,
"bookmark": "chart — grouped bars · multi-series · gridlines",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "values is an array of { field, name, color }: each series reads its own field, bars group per category, and the legend lists the names. gridlines adds the value axis.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 71.7,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 71.7,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"chart\", \"kind\": \"bar\", \"data\": \"quarters\", \"label\": \"q\",\n \"gridlines\": true, \"width\": 495, \"height\": 150,\n \"values\": [ { \"field\": \"fy25\", \"name\": \"FY 2025\", \"color\": \"94a3b8\" },\n { \"field\": \"fy26\", \"name\": \"FY 2026\", \"color\": \"0F766E\" } ] }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "chart",
"kind": "bar",
"data": "quarters",
"label": "q",
"gridlines": true,
"width": 495,
"height": 150,
"title": "Grouped — one bar per series",
"values": [
{
"field": "fy25",
"name": "FY 2025",
"color": "94a3b8"
},
{
"field": "fy26",
"name": "FY 2026",
"color": "0F766E"
}
]
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "chart — stacked bars",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 327.35,
"bookmark": "chart — stacked bars",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "mode \"stacked\" piles the series per category instead of grouping them; a colors palette is cycled when series set no colour of their own.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 71.7,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 71.7,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"chart\", \"kind\": \"bar\", \"mode\": \"stacked\",\n \"data\": \"quarters\", \"label\": \"q\", \"gridlines\": true,\n \"colors\": [ \"0F766E\", \"f59e0b\" ],\n \"values\": [ { \"field\": \"fy25\" }, { \"field\": \"fy26\" } ] }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "chart",
"kind": "bar",
"data": "quarters",
"label": "q",
"gridlines": true,
"width": 495,
"height": 150,
"title": "Stacked — series pile per category",
"mode": "stacked",
"colors": [
"0F766E",
"f59e0b"
],
"values": [
{
"field": "fy25",
"name": "FY 2025"
},
{
"field": "fy26",
"name": "FY 2026"
}
]
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "chart — line",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 271.35,
"bookmark": "chart — line",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "One line per series over the category axis; share the same data binding as the bar charts.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 58.525,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 58.525,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"chart\", \"kind\": \"line\", \"data\": \"quarters\", \"label\": \"q\",\n \"width\": 495, \"height\": 120,\n \"values\": [ { \"field\": \"fy26\", \"name\": \"FY 2026\", \"color\": \"0F766E\" } ] }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "chart",
"kind": "line",
"title": "FY 2026 by quarter",
"data": "quarters",
"label": "q",
"values": [
{
"field": "fy26",
"name": "FY 2026",
"color": "0F766E"
}
],
"width": 495,
"height": 120
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "chart — pie & donut",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 448.175,
"bookmark": "chart — pie & donut",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "points may be inline instead of data-bound. pie draws a swatch + percentage legend; donut is a pie with a ring cutout (\"kind\": \"donut\").",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 58.525,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 58.525,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"chart\", \"kind\": \"pie\", \"width\": 240, \"height\": 130,\n \"points\": [ { \"label\": \"Templates\", \"value\": 45 },\n { \"label\": \"Charts\", \"value\": 25 }, ... ] }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "chart",
"kind": "pie",
"title": "Pie",
"legend": true,
"width": 495,
"height": 128,
"points": [
{
"label": "Templates",
"value": 45
},
{
"label": "Charts",
"value": 25
},
{
"label": "Codes",
"value": 18
},
{
"label": "Everything else",
"value": 12
}
]
},
{
"type": "move",
"x": 0,
"y": 6
},
{
"type": "chart",
"kind": "donut",
"title": "Donut",
"legend": true,
"width": 495,
"height": 128,
"points": [
{
"label": "Templates",
"value": 45
},
{
"label": "Charts",
"value": 25
},
{
"label": "Codes",
"value": 18
},
{
"label": "Everything else",
"value": 12
}
]
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "page_break"
},
{
"type": "rect",
"width": 30,
"height": 30,
"fill": "0F766E",
"radius": 8
},
{
"type": "move",
"x": 11,
"y": 6
},
{
"type": "paragraph",
"value": "5",
"options": {
"fontSize": 13,
"fontWeight": "bold",
"color": "ffffff"
}
},
{
"type": "move",
"x": 30,
"y": -19
},
{
"type": "paragraph",
"value": "Layout & render options",
"options": {
"fontSize": 20,
"fontWeight": "bold",
"color": "0f172a",
"bookmark": "Layout & render options",
"anchor": "sec-layout"
}
},
{
"type": "move",
"x": -41,
"y": 12
},
{
"type": "paragraph",
"value": "Multi-column flow, data-driven branches, and the options that live in the render call rather than the template.",
"options": {
"fontSize": 10,
"color": "64748b",
"italic": true
}
},
{
"type": "move",
"x": 0,
"y": 10
},
{
"type": "hr",
"color": "e2e8f0",
"thickness": 0.8
},
{
"type": "move",
"x": 0,
"y": 16
},
{
"type": "paragraph",
"value": "columns — multi-column flow",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 259.0,
"bookmark": "columns — multi-column flow",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "Children fill column 1 to the bottom, then column 2 (sequential fill); a page_break inside is a column break. Everything flows — paragraphs, lists, images, tables and charts. A table that overflows a column continues in the next one with its header repeated.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 58.525,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 58.525,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"columns\", \"count\": 2, \"gap\": 22, \"content\": [\n { \"type\": \"paragraph\", \"value\": \"flows down column 1...\" },\n { \"type\": \"table\", \"header_columns\": [...], \"rows\": [...] } ] }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "columns",
"count": 2,
"gap": 22,
"content": [
{
"type": "paragraph",
"value": "Column one fills top to bottom, then the flow hops into column two automatically — sequential fill. A table renders inline too:",
"options": {
"fontSize": 9,
"alignment": "justify",
"color": "475569",
"spacing": 6
}
},
{
"type": "table",
"options": {
"padding_x": 4,
"padding_y": 2,
"stripe": "f1f5f9",
"header": {
"fillColor": "0F766E",
"textColor": "ffffff"
}
},
"header_columns": [
{
"text": "Item",
"width": 92,
"fontWeight": "bold"
},
{
"text": "Qty",
"width": 48,
"fontWeight": "bold"
}
],
"rows": [
[
{
"text": "Widgets",
"width": 92
},
{
"text": "12",
"width": 48
}
],
[
{
"text": "Gadgets",
"width": 92
},
{
"text": "5",
"width": 48
}
],
[
{
"text": "Sprockets",
"width": 92
},
{
"text": "9",
"width": 48
}
]
]
},
{
"type": "paragraph",
"value": "…and the paragraph after the table keeps flowing, spilling into the second column to show the block is genuinely two columns.",
"options": {
"fontSize": 9,
"alignment": "justify",
"color": "0F766E",
"fontWeight": "bold",
"spacing": 6
}
}
]
},
{
"type": "move",
"x": 0,
"y": 6
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "if / unless — data-driven branches",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 180.175,
"bookmark": "if / unless — data-driven branches",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "Render content only when a condition holds (if) or fails (unless); an optional else is the other branch. With equals it is a string test, otherwise a truthiness test.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 58.525,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 58.525,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "{ \"type\": \"if\", \"when\": \"doc.paid\", \"equals\": \"true\",\n \"content\": [ { \"type\": \"paragraph\", \"value\": \"PAID IN FULL\" } ],\n \"else\": [ { \"type\": \"paragraph\", \"value\": \"Balance due\" } ] }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "if",
"when": "doc.paid",
"equals": "true",
"content": [
{
"type": "paragraph",
"spans": [
{
"text": "PAID IN FULL",
"fontWeight": "bold",
"color": "16a34a"
},
{
"text": " — doc.paid is \"true\", so the content branch renders (the else branch is skipped).",
"color": "64748b",
"fontSize": 9
}
],
"options": {
"fontSize": 10.5
}
}
],
"else": [
{
"type": "paragraph",
"value": "Balance due",
"options": {
"color": "b91c1c"
}
}
]
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "interpolation & page tokens",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 170,
"bookmark": "interpolation & page tokens",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "A dotted path pulls from the data; page tokens resolve after pagination and turn a contents list into real page numbers. Print a literal brace token by doubling the dollar.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 58.525,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 58.525,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"spans": [
{
"text": "\"Invoice "
},
{
"text": "$${invoice.number}",
"color": "0F766E"
},
{
"text": " — page "
},
{
"text": "#PAGE#",
"color": "0F766E"
},
{
"text": " of "
},
{
"text": "#TOTAL_PAGE#",
"color": "0F766E"
},
{
"text": "\""
}
],
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "paragraph",
"spans": [
{
"text": "\"See charts on p. "
},
{
"text": "#PAGE_OF:sec-charts#",
"color": "0F766E"
},
{
"text": "\" with "
},
{
"text": "\"linkTo\": \"sec-charts\"",
"color": "64748b"
}
],
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "paragraph",
"spans": [
{
"text": "\""
},
{
"text": "$${",
"color": "b45309"
},
{
"text": " prints a literal "
},
{
"text": "${",
"color": "b45309"
},
{
"text": "\" — this document's code boxes rely on it",
"color": "64748b"
}
],
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "paragraph",
"value": "renders",
"options": {
"fontSize": 7.5,
"mono": true,
"color": "94a3b8",
"spacing": 3
}
},
{
"type": "paragraph",
"spans": [
{
"text": "The running header and footer of this page both resolve "
},
{
"text": "#PAGE#",
"mono": true,
"color": "0F766E"
},
{
"text": " / "
},
{
"text": "#TOTAL_PAGE#",
"mono": true,
"color": "0F766E"
},
{
"text": ", and the cover's contents used "
},
{
"text": "#PAGE_OF:…#",
"mono": true,
"color": "0F766E"
},
{
"text": " for its page numbers."
}
],
"options": {
"fontSize": 10,
"color": "334155",
"lineHeight": 1.4
}
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "document options",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 176.52499999999998,
"bookmark": "document options",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "The options block sets page size, margins, the reserved header_height, a page background or backgroundImage (this cover's wash — opacity fades it to a soft tint), a document watermark, and tagged for accessible output.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 98.05,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 98.05,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "\"options\": {\n \"page\": \"a4\", \"margins\": { \"top\": 42, \"left\": 50 },\n \"header_height\": 34,\n \"watermark\": { \"text\": \"DRAFT\", \"front\": true, \"pages\": \"first\" },\n \"backgroundImage\": { \"src\": \"...\", \"pages\": \"first\",\n \"opacity\": 0.15 } }",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "paragraph",
"value": "the render call — pdf_render(tpl, data, options)",
"options": {
"fontSize": 12,
"fontWeight": "bold",
"mono": true,
"color": "0F766E",
"minSpaceBelow": 150.525,
"bookmark": "the render call — pdf_render(tpl, data, options)",
"bookmarkLevel": 2
}
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "paragraph",
"value": "Some features live in the call, not the template JSON: a letterhead to draw on, files to embed, Info-dictionary metadata, a password, or PDF/A archival output.",
"options": {
"fontSize": 9.5,
"color": "64748b",
"lineHeight": 1.35
}
},
{
"type": "move",
"x": 0,
"y": 7
},
{
"type": "rect",
"width": 495,
"height": 84.875,
"fill": "f8fafc",
"border": "e2e8f0",
"borderWidth": 0.8,
"radius": 6
},
{
"type": "rect",
"width": 3,
"height": 84.875,
"fill": "0F766E",
"radius": 1.5
},
{
"type": "move",
"x": 15,
"y": 10
},
{
"type": "paragraph",
"value": "pdf_render(tpl, data, {\n \"stationery\": \"pdf/letterhead.pdf\", # draw on a letterhead PDF\n \"attachments\": [{ \"path\": \"data.csv\" }],\n \"title\": \"Invoice 42\", \"author\": \"Soli\",\n \"font_dirs\": [\"font\"], \"fetch_images\": false })",
"options": {
"fontSize": 8.5,
"mono": true,
"color": "334155",
"lineHeight": 1.55
}
},
{
"type": "move",
"x": -15,
"y": 22
},
{
"type": "move",
"x": 0,
"y": 24
},
{
"type": "move",
"x": 0,
"y": 4
},
{
"type": "rect",
"width": 495,
"height": 58,
"fill": "0F766E",
"radius": 12
},
{
"type": "rect",
"width": 495,
"height": 4,
"fill": "f59e0b",
"radius": 2
},
{
"type": "move",
"x": 22,
"y": 13
},
{
"type": "paragraph",
"value": "Built with Soli — one JSON template, one pdf_render() call.",
"options": {
"fontSize": 13,
"fontWeight": "bold",
"color": "ffffff"
}
},
{
"type": "paragraph",
"value": "solilang.com/docs/builtins/pdf · try this very template live in the playground",
"options": {
"fontSize": 9,
"color": "ccfbf1",
"link": "https://solilang.com/docs/builtins/pdf"
}
},
{
"type": "move",
"x": -22,
"y": 20
}
]
}
features.data.json
json
{
"data": {
"invoice": {
"number": "INV-2026-0042"
},
"doc": {
"ref": "TOUR-2026-001",
"paid": "true",
"total": "1,940.00 EUR"
},
"payment": {
"name": "Soli Demo SARL",
"iban": "FR7630006000011234567890189",
"amount": "79.00"
},
"items": [
{
"name": "Template engine",
"qty": "1",
"amount": "890.00 EUR"
},
{
"name": "Chart pack (bar · line · pie · donut)",
"qty": "4",
"amount": "450.00 EUR"
},
{
"name": "QR & barcode primitives",
"qty": "2",
"amount": "300.00 EUR"
},
{
"name": "Factur-X / PDF-A-3b embedding",
"qty": "1",
"amount": "300.00 EUR"
}
],
"milestones": [
{
"date": "2026-03",
"title": "Charts & lists",
"note": "bar, line, pie, nested lists"
},
{
"date": "2026-06",
"title": "SVG & barcodes",
"note": "crisp vector logos, Code 128 / EAN"
},
{
"date": "2026-07",
"title": "Flow & polish",
"note": "columns, tokens, the ${ escape"
}
],
"quarters": [
{
"q": "Q1",
"fy25": 120,
"fy26": 180
},
{
"q": "Q2",
"fy25": 150,
"fy26": 210
},
{
"q": "Q3",
"fy25": 170,
"fy26": 260
},
{
"q": "Q4",
"fy25": 160,
"fy26": 300
}
]
}
}More in Showcase
