Vector graphics (SVG)

SVG logos, icons and gradients embedded as real vectors, sharp at any size.

SVG sources are auto-detected and embedded as PDF form XObjects rather than rasterised.

SVG images data: URIs 1 page

Open PDF Download PDF Edit in playground

render_graphics.rb ruby

require 'json'
require 'soli/pdf'

template = JSON.parse(File.read('graphics.template.json'))
data     = JSON.parse(File.read('graphics.data.json'))

pdf = Soli::PDF.render(
  template: template,
  data: data,
  title: 'Vector graphics'
)
File.binwrite('graphics.pdf', pdf)

Run it yourself

Add the gem to your Gemfile — see Installation.
Download graphics.template.json and graphics.data.json.
Run ruby render_graphics.rb.

graphics.template.json json

{
  "fonts": ["TitilliumWeb"],
  "options": { "margins": 48 },
  "content": [
    { "type": "paragraph", "spans": [ { "text": "Vector graphics (SVG)", "color": "0f766e", "fontWeight": "bold" } ], "options": { "fontSize": 22 } },
    { "type": "paragraph", "spans": [ { "text": "SVG sources are auto-detected and rasterised — logos and icons stay crisp at any placed size.", "color": "6b7280" } ], "options": { "fontSize": 11 } },
    { "type": "move", "y": 18 },

    { "type": "paragraph", "value": "Logo", "options": { "fontSize": 13, "fontWeight": "bold" } },
    { "type": "move", "y": 6 },
    { "type": "image", "width": 120,
    { "type": "move", "y": 56 },

    { "type": "paragraph", "value": "Icons", "options": { "fontSize": 13, "fontWeight": "bold" } },
    { "type": "move", "y": 6 },
    { "type": "image", "width": 40,
    { "type": "move", "x": 52 },
    { "type": "image", "width": 40,
    { "type": "move", "x": 52 },
    { "type": "image", "width": 40,
    { "type": "move", "x": -104, "y": 56 },

    { "type": "paragraph", "value": "A gradient", "options": { "fontSize": 13, "fontWeight": "bold" } },
    { "type": "move", "y": 6 },
    { "type": "image", "width": 300,
  ]
}

graphics.data.json json

{}
